Specifications

Connection Size: 1″-2″ Threaded, 3″ Flanged
Connection Type: Threaded, Flanged, Butt Weld, and Victaulic End
Body Style: Angle Body
Body Material: 316 SS
Process Fluid: Gas, Liquid, Vapor, Steam (MDAS)
Max. Working Pressure: 5,000 psi – MAWP 1,333 psi for steam
CV Range: 1″ – 2″: 0.70 – 23.86, 3”: 11.2 -100.74

Additional Benefits

• Accurate Control – 90-degree rotation from Full Off to Full On
• Bolted Body – The body is constructed with two bolted segments, avoiding the risk of corrosion, cross-threading, and galling of threaded type valve assemblies.
• Extended Mean Time Between Service – Robust design and liberal application of hardened materials, efficient flow-geometry means the valves offer maximum production potential and minimum service requirements.
• Easy Maintenance – Choke valves are designed to provide simple straightforward disassembly with no special tooling or fixtures.

Applications

High-pressure drop applications in gas, liquid, and vapor. Quick open/close with abrasive fluids at high-pressure drops.

• Well Site Automation
• Blow Down and Dump Valve
• Water Injection Control Valve
• Remote Control for directional drilling
• CO2 Injection Control Valve
• Steam Injection
• Pump Bypass
• Steam Tracer Control
• Pump Startup
• Manual and Automated Application
• Gas Lift Injection Control
• High-Temperature Protection
