RUPTURE PIN PRODUCTS

High quality U.S. manufactured valves designed to meet many options encountered in the oil and gas industry.
Where to Buy
Model C-ASME Pressure Relief Valve
Model C-ASME Pressure Relief Valve
ModelC-ASME-Open-Close-SetUp
Model C-ASME Pressure Relief Valves
Model C-ASME Pressure Relief Valve
Model C-ASME Pressure Relief Valve
ModelC-ASME-Open-Close-SetUp

Model C-ASME

The Model C-ASME is the ASME-certified version of our angle body Model C relief valve. The Model C-ASME is UD stamped. It holds a bubble-tight, closed position until pressure reaches an exact set point. At set point, the valve instantly opens to relieve pressure from a protected system. The valve features a wide variety of pressure ratings and settings.





SKU: RP-PRV-Model-C-ASME Categories: ,

Specifications

  • Set Pressure: 15 – 1,480 PSI
  • Accuracy: + / – 5% above 40 PSI, ±2 PSI Below 40 PSI
  • Connections: Flange connections are available.
  • Seals: Available for high & low temperatures, Viton standard.
  • Standard Materials: ASME Section II materials.

The C-ASME now offers the same inlet and outlet connections with the option of having the outlet being one size larger than the inlet.

Download the brochure for complete details on the features, advantages, and benefits of the Model C-ASME valve.

NOTE: Taylor Valve reserves the right to change product designs and specifications without notice.

Applications

The Model C-ASME relief valve is designed specifically to be installed on ASME Section VIII UD coded vessels. It provides safety for a variety of pressure relief applications including but not limited to: Oil and Gas Production, Pipeline, Well Drilling, Chemical Processing, Food Processing, Waste Water Processing, Pharmaceutical Processing, Pulp and Paper Plants, and anywhere that conventional relief valves and rupture discs are used.

Valve Options

Valve Options: Sensors

Sensor Option

Valves can be equipped with a sensor option that allows for remote monitoring of the valves status.

Valve Options: Pin Holder

Pin Holder

Pin holders are a great way to keep replacement pins ready to go right on the valve for when you need them

Valve Options: Safety Pin Cage

Safety Pin Cage

Add a safety pin cage to protect against foreign objects from interfering with the operation of the pin.

Valve Options: Flush Port

Flush Port

Add a flush port to add the ability to clean out the inside of the valve.
